ECADLens

Status: early development. Initial focus: Gerber comparison for PCB fabrication review.

Tolerance-aware PCB fabrication file comparison.

ECADLens is a desktop tool for comparing PCB fabrication files, reviewing differences, filtering harmless manufacturing variation, and producing approval reports.

Generic file comparison tools are noisy for PCB review. ECADLens is being built for engineers who need to compare Gerbers and other ECAD fabrication outputs while ignoring harmless manufacturing-level differences.

Join early access Contact

Built by an electronics engineer for PCB review workflows.

Built for

PCB reviewers who need a quieter diff.

Electronics engineers
PCB reviewers
Fabrication file approval workflows
Gerber comparison and inspection

Feature direction

Planned review workflow coverage.

Layer-by-layer fabrication file comparison
Tolerance-aware difference filtering
Visual inspection workflow
Approval and review notes
Exportable comparison reports
Built for Windows and Linux desktop workflows

Coming soon. Windows and Linux planned.
